SLITTING LINE NOVASTILMEC 850X3 COD R089 - ROLM

MATERIAL:

THICKNESS:

USEFUL WIDTH:

DECOILER CAPACITY:

INN COIL DIAMETER:

MAX EXT COIL DIAMETER:

DECOILING:

RECOILER CAPACITY:

INN COIL DIAMETER:

MAX EXT COIL DIAMETER:

RECOILING:

SPEED:

CIRC SHEAR SHAFT DIAMETER:

DIRECTION:

CARBON STEEL

0.2 up to 3 mm

850 mm

12.000 Kg

400/500/700 mm

1500 mm

FROM TOP

12.000 Kg

500 mm

1500 mm

FROM TOP

120 mt

160 mm

LEFT to RIGHT

PLANT COMPOSITION:

• COIL CAR "ON FLOOR"

• SINGLE MANDREL DECOILER


• ENTRY TABLE


• MOTORIZED PINCHROLL

• CONTAINING ROLLS + SIDE GUIDE GROUP


• CIRCULAR SHEAR


• SCRAP BALER

• ENTRY RAMP


• EXIT RAMP


• N°2 SEPARATORS


• FELT PRESS


• CROP SHEAR "S" TYPE TENSIONING SYSTEM

• EXIT TABLE


• RECOILER


• COIL UNLOADING CAR WITH CONTAINING SYSTEM

• TURRET 2 ARMS


• ELECTRICAL CABINET


• CONTROL DESK


• HYDRAULIC UNITS


• USED TOOLING SET
